Product Description
Flexo Printing Machine is a highly versatile and efficient printing method. It is commonly used for packaging, labels, and other commercial applications. This machine is capable of printing large volumes efficiently and can print on paper, plastic, metal, and fabric. This is suitable for diverse printing requirements as it allows quick changes to printing and design parameters. Our machines are known for their ability to print at high speeds and reused for multiple runs. We ensure this can print on both porous and non-porous surfaces. Robust Unwinder & Rewinder permits smooth flow of jobs and Superior Technology Control Panel allows easy customer interface. The ink is solvent-based, compatible with water-based, smudge-proof and UV-curable inks. Also, these machines minimize the waste generated during production. You can avail these machines in different specifications as per the requirement. They are highly admired for their numerous features such as flexible Starting, eco-friendly, reliable drying system, easy Operation, accurate color register and much more. Apart from this, the Flexo Printing Machine is widely used in industries such as food packaging, labels, consumer goods, newspapers and mass media, industrial products and so on. We are providin these printing machines at pocket-friendly rates.
Flexo Printing Machine is provided with an optimum flexographic printing method. It is offered with a special drying process and is compatible with wide variety of ink types. Based on the surface type and application, this is ideal for wallpaper, plastics etc. Flexo Printing Machine is offered with reduced drying time and works with the assistance of extremely effective two-step process. Making use of a flexible relief plate, this can do printing on several substrates such as paper, plastic, metallic films and others. It has a modern printing technique, mostly utilized for cellophane, thermo-foils and carton.
Product Details of Flexo Printing Machine:
Color Printing
|
Color Printing
|
Automatic Grade
|
Automatic
|
Size
|
1200 mm
|
Anilox Roller (Line)
|
4
|
Material Width
|
1200mm
|
Printing Width
|
1160mm
|
Model Number
|
E4120
|
Condition
|
New
|
Max Printing Length (mm)
|
500-1000,1000-1500,0-500
|
Printing Machine Type
|
Flexographic Printing Machine
|
Application
|
Non Woven
|
Machine Type
|
Automatic
|
Specification
Specification
Model 1
|
Model 2
|
Model 3
|
Model 4
|
Model 5
|
Model 6
|
Printing Color
|
4
|
2
|
4
|
4
|
4
|
4
|
Material Feeding Width
|
1200 mm
|
1200 mm
|
1400 mm
|
1600 mm
|
1300 mm
|
1300 mm
|
Max Printing Width
|
1160 mm
|
1160 mm
|
1360 mm
|
1560 mm
|
1260 mm
|
1260 mm
|
Web Guide
|
EPC
|
-
|
EPC
|
EPC
|
EPC
|
EPC
|
Printing Speed
|
3 - 50 m/min
|
3 - 50 m/min
|
3 - 50 m/min
|
3 - 50 m/min
|
3 - 80 m/min
|
3 - 80 m/min
|
Cylinder Rolls
|
Anilox Steel
|
Anilox Steel
|
Anilox Steel
|
Anilox Steel
|
Anilox Steel
|
Ceramic
|
Plate Lifting
|
Pneumatic
|
Pneumatic
|
Pneumatic
|
Pneumatic
|
Hydraulic
|
Hydraulic
|
Gear Drive
|
Spur
|
Spur
|
Spur
|
Spur
|
Helical
|
Helical
|
Registration Precision
|
Moderate
|
Moderate
|
Moderate
|
Moderate
|
High
|
High
|
Un & Rewind Type
|
5 Kg. Airshaft
|
5 Kg. Airshaft
|
5 Kg. Airshaft
|
5 Kg. Airshaft
|
10 Kg. Airshaft
|
10 Kg. Airshaft
|
Un-Rewind Roller
|
1000 mm
|
1000 mm
|
1000 mm
|
1000 mm
|
1000 mm
|
1000 mm
|
Loading Type
|
Pneumatic
|
Pneumatic
|
Pneumatic
|
Pneumatic
|
Pneumatic
|
Pneumatic
|
Doctor Blade
|
-
|
-
|
-
|
-
|
Single Side
|
Single Side
|
No of Fans to Dry
|
2
|
2
|
2
|
2
|
3
|
3
|
Heat Power
|
20 KW
|
18 KW
|
20 KW
|
20 KW
|
21 KW
|
21 KW
|
Total Power
|
25 KW
|
22 KW
|
25 KW
|
25 KW
|
34 KW
|
34 KW
|
Power Supply
|
3 Phase / 415v / 50Hz
|
3 Phase / 415v / 50Hz
|
3 Phase / 415v / 50Hz
|
3 Phase / 415v / 50Hz
|
3 Phase / 415v / 50Hz
|
3 Phase / 415v / 50Hz
|
Weight (Approx.)
|
3500 Kgs
|
2200 Kgs
|
3700 Kgs
|
3900 Kgs
|
5000 Kgs
|
5200 Kgs
|
Dimension (WxLxH) mm
|
2400x5200x2700
|
2400x3200x2700
|
2600x5200x2700
|
2800x5200x2700
|
2800x6000x3500
|
2800x6000x3500
|
|
FAQs of Flexo Printing Machine:
Q: Is the Flexo Printing Machine easy to operate?
A: Yes, the Flexo Printing Machine is computerized, making it easy to operate and control.
Q: What is the weight of the Flexo Printing Machine?
A: The Flexo Printing Machine weighs 1000 kilograms.
Q: What power does the Flexo Printing Machine require?
A: The Flexo Printing Machine is powered by 220 volts.
Q: What type of printing does the Flexo Printing Machine produce?
A: The Flexo Printing Machine is a Flexo Printing Machine type, which produces clear, precise, and sharp prints.
Q: What industries can use the Flexo Printing Machine?
A: The Flexo Printing Machine is perfect for businesses in the packaging, labeling, and printing industries.
